13. Slide the optical drive assembly into the media bay until it clicks into place.
14. Connect the optical drive SATA-power Y-cable
.
15. If removed, install the air baffle
.
16. Install the access panel
.
17. Install the front bezel
.
18. Do one of the following:
If the server is in tower mode: Position the tower server for operation .
If the server is in rack mode: Install the server on the tray .
19. Connect all peripheral cables to the server.
20. Connect the power cords:
a. Connect each power cord to the server.
b. Connect each power cord to the power source.
21. Power up the server
.
The installation is complete.
