Component identification 14
Item Description
12
Storage backup power connectors
13
SATA port 4
14
SATA port 5
15
Internal USB 3.0 connector
16
x4 SATA port 2
17
x4 SATA port 1
18
Internal USB 2.0 connector
19
Flexible Smart Array Controller connector
20
Internal USB tape drive connector
21
Micro SD card slot
22
DIMM slots for processor 2
23
HP Systems Insight Display connector
24
External thermal cable connector
25
Front I/O connector
26
24-pin power supply connector
27
Processor 2
28
29
8-pin power supply connector
30
Fan cage power connector
31
HP Smart Storage Battery connector
32
System battery holder
33
Discovery service connector
34
System maintenance switch
35
NMI header
36
TPM connector
37
Storage backup power connectors
NMI functionality
An NMI crash dump creates a crash dump log before resetting a system which is not responding.
Crash dump log analysis is an essential part of diagnosing reliability problems, such as failures of operating
systems, device drivers, and applications. Many crashes freeze a system, and the only available action for
administrators is to restart the system. Resetting the system erases any information which could support
problem analysis, but the NMI feature preserves that information by performing a memory dump before a
system reset.
To force the system to invoke the NMI handler and generate a crash dump log, do one of the following:
• Use the iLO Virtual NMI feature.
• Short the NMI header ("System board components" on page 13).
For more information, see the HP website (http://www.hp.com/support/NMI).
