Component identification 15
DIMM slots
DIMM slots are numbered sequentially (1 through 12) for each processor. The supported AMP modes use the
letter assignments for population guidelines.
The arrow points to the front of the server.
System maintenanace switch
Position Default Function
S1
Off Off = iLO security is enabled.
On = iLO security is disabled.
S2
Off Off = System configuration can be
changed.
On = System configuration is locked.
