Hardware options installation 80
o SFF configuration
13. Install the access panel (on page 32).
14. Do one of the following:
o If the server is in a tower configuration, return the server to an upright position.
o If the server is in a rack configuration, slide the server into the rack.
15. Connect each power cord to the server.
16. Connect each power cord to the power source.
17. Power up the server (on page 29).
18. Do one of the following:
o For tower models, install the tower bezel (on page 31).
o For rack models, install the security bezel ("Security bezel option" on page 48).
Second processor option
The server supports single-processor and dual-processor operation.
When processor 2 is installed, fan 1 must also be installed. For more information see "Hot-plug fans (on page
26)."
CAUTION: To avoid damage to the processor and system board, only authorized personnel
should attempt to replace or install the processor in this server.
CAUTION: To prevent possible server malfunction and damage to the equipment, multiprocessor
configurations must contain processors with the same part number.
IMPORTANT: If installing a processor with a faster speed, update the system ROM before
installing the processor.
To install a processor:
1. Do one of the following:
