Hardware options installation 54
22. Install the SID blank.
23. Install the access panel (on page 32).
24. Install the server onto the rack rails, and then slide the assembly into the rack.
NOTE: For detailed instructions on installing the server into the rack, see the Quick Deploy Rail
System Installation Instructions included with the kit.
25. Connect peripheral devices to the server. For information on identifying connectors, see "Rear panel
components (on page 11)."
WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug
telephone or telecommunications connectors into RJ-45 connectors.
26. Connect the power cord to the rear of the server.
27. Connect the power cord to the power source.
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
•
Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
Systems Insight Display option
The HP Systems Insight Display (SID) is only available as an option for rack configurations.
1. If installed, remove the security bezel ("Remove the security bezel (optional)" on page 30).
2. Power down the server (on page 29).
3. Remove all power:
