Edge Switch 2/24 installation guide 29
5. Connect the U.S. or country-specific (optional) AC power cords to the right (PS0) and left (PS1)
receptacles at the rear of the chassis.
WARNING! IAn HP-supplied power cord is provided for each Edge Switch power supply.
To prevent electric shock when connecting the Edge Switch to primary facility power, use only
the supplied power cords, and ensure that the facility power receptacle is the correct type,
supplies the required voltage, and is properly grounded.
6. Connect the remaining ends of the AC power cords to separate facility power sources that
provide single-phase, 90 to 264 volt alternating current (VAC) current. This provides power
redundancy.
When the first power cord is connected, the Edge Switch powers on and performs power-on
self-tests (POSTs). During POSTs:
a. The green power (PWR) LED on the front panel illuminates.
b. The amber system error (ERR) LED on the front panel blinks momentarily while the Edge
Switch is tested.
c. The green LEDs associated with the Ethernet port blink momentarily while the port is tested.
d. The green/blue and amber LEDs associated with Fibre Channel ports blink momentarily
while the ports are tested.
7. After successful POST completion, the green power (PWR) LED remains ON and all other front
panel LEDs turn OFF.
8. If a POST error or other malfunction occurs, refer to the HP StorageWorks Edge Switch 2/24
service manual to isolate the problem.
9. Perform the following steps:
• If you manage the switch through EWS, go to ”Using the Embedded Web Server” on
page 67 to configure the switch.
• If you manage the switch through HAFM, go to ”Configure switch network information” on
page 34.
Install the Edge Switch in a rack
This section describes how to rack mount the HP StorageWorks Edge Switch 2/24 in the
appropriate HP, or comparable, 19-inch Electronic Industries Association (EIA) rack:
• HP 9000 series, 10000 series, and 11000 series racks
• HP rack system/e or 19-inch EIA rack
