Technical specifications98
Power requirements
Table 8 lists Edge Switch 2/24 power requirements.
Operating tolerances
Table 9 lists heating and cooling specifications, shock tolerances, vibration, acoustical noise, and
inclination.
Maximum wet-bulb
temperature
84° F (29° C) 84°F (29°C) 81°F (27°C)
Altitude 40,000 ft
(12,192 m)
40,000 ft
(12,192 m)
10,000 ft
(3,048 m)
Table 7 Environmental specifications (continued)
Specification Shipping Storage Operating
Table 8 Power requirements
Specification Value
Input voltage 90 to 264 VAC
Input frequency 47 to 63 Hz
Table 9 Operating tolerances
Specification Value
Heat dissipation 49 watts (167 BTU/hr)
Cooling airflow clearances Right and left sides: 1.3 cm (0.5 inches)
Front and rear: 7.6 cm (3.0 in)
Top and bottom: No clearance required
Shock and vibration tolerance 60 Gs for 10 milliseconds without nonrecoverable errors
Acoustical noise 70 dB “A” scale
Inclination 10° maximum
