Lucid ADA 88192 Converter Settings for Remote Control
You must configure the following settings to control the converter remotely. Any setting not listed here
either has no effect with the application or can be set through the audio preferences of the application.
CommentMenu ItemMenu
ADAT INs: SRC ON
ADAT INs: SMUX OFF
ADAT
AES IN1+2: SRC OFF
AES IN3+4: SRC OFF
AES IN5+6: SRC OFF
AES IN7+8: SRC OFF
AES
IN1+2: SoftClip OFF
IN3+4: SoftClip OFF
IN5+6: SoftClip OFF
IN7+8: SoftClip OFF
Analog
Analog INs: SoftClip
3 is the recommended settingClip Detect: 3Meter
8 is the recommended settingRoute Unit: 8System
Miscellany
Lucid ADA 88192 Converter Settings for Local Control
You must configure the following settings to control the converter locally. Any setting not listed here either
has no effect with the application or can be set to any of the values available for it.
CommentMenu ItemMenu
ADAT INs: SRC ON
ADAT INs: SMUX OFF
ADAT
AES IN1+2: SRC OFF
AES IN3+4: SRC OFF
AES IN5+6: SRC OFF
AES IN7+8: SRC OFF
AES
IN1+2: SoftClip ON
IN3+4: SoftClip ON
IN5+6: SoftClip ON
IN7+8: SoftClip ON
Analog
Analog INs: SoftClip
set each input channel to a value in
the range -95.5 to +31.5 dB
Analog
Analog INs: Gain
set either -10 or +4 for each output
channel
Analog
Analog OUTs: Level
3 is the recommended settingClip Detect: 3Meter
If these options do not appear, verify that Route Unit
(in the System, Miscellany menu) is set to 8.
For analog audio:
AES INs --> ADAT OUTs
Analog INs --> AES OUTs
AES INs --> Analog OUTs
Route
Lucid ADA 88192 Converter Settings for Remote Control | 35

HP xw8600 Specifications

General

Chipset	Intel 5400
Form Factor	Tower
Processor	Intel Xeon 5400 series
Memory	Up to 32GB DDR2 FB-DIMM
Storage	SATA or SAS hard drives
Graphics	NVIDIA Quadro or ATI FirePro
Operating System	Windows XP, Vista, or Linux
Expansion Slots	PCI, PCI-X, PCIe
Power Supply	800W
