HP xw9400 - POST Error Messages

POST error messages
POST is a program run at startup that initializes and runs some tests on installed hardware. An audible
and/or visual message occurs if the POST encounters a problem. POST checks the following items to
ensure that the workstation system is functioning properly:
●
Keyboard
●
Memory modules
●
Diskette drives
●
All SATA, IDE, and SAS mass storage devices
●
Processors
●
Controllers
NOTE If the Power-On Password is set, a key icon appears on the screen while POST is
running. You must enter the password before continuing.
Table 5-18 POST error messages
Screen Message Probable Cause Recommended Action
101–Option ROM Error. Plug-in card ROM checksum. Update the ROM on the card.
102–System Board Failure DMA, timers.
CAUTION Disconnect AC power from the
workstation before reseating or replacing
components because there is power to the
system board even when the workstation is
powered down.
1. Clear CMOS by pressing the Clear CMOS button
on the system board.
2. Remove expansion boards.
3. Replace the system board.
103–System Board Failure DMA, timers.
CAUTION Disconnect AC power from the
workstation before reseating or replacing
components because there is power to the
system board even when the workstation is
powered down.
1. Clear CMOS by pressing the Clear CMOS button
on the system board.
2. Remove expansion boards.
3. Replace the system board.
110–Out of Memory Space for
Option ROMs
Option ROM for a device was unable
to run due to memory constraints.
Remove expansion boards and disable unneeded
devices from I/O>Onboard Devices or
Storage>Storage Options. Run Computer Setup
(F10).
ENWW POST error messages 131
