Product specifications
The following table lists the physical dimensions.
Table 1-4 Physical characteristics
Weight (depending on
configuration)
18-27.7 kg (39.6-61.1 lb.)
Tower dimensions 455 mm (17.9 in.) tall, 210 mm (8.3 in.) wide, 525 mm (20.7
in.) deep
Rack mount dimensions (top
cover and foot removed)
210 mm (8.3 in.) tall, 440 mm (17.3 in.) wide, 525 mm (20.7
in.) deep
Power supply and cooling
This section describes power supply specifications.
Table 1-5 Voltage specification
Voltage Minimum Maximum Description
3.3 V 3.17 V 3.47 V Used with PCI, onboard logic, SAS controller, IEEE 1394,
and chipset
5 V 4.90 V 5.35 V Used with storage (disk, optical, diskette), PCI, Audio,
USB, input to onboard regulator, and onboard logic
12 V CPU0 11.52 V 12.6 V Input to onboard regulator that supplies power for CPU 0
12 V CPU1 11.52 V 12.6 V Input to onboard regulators that supply power for CPU1
and the chipset
12 V-M 11.52 V 12.6 V Input to onboard regulators that supply power for memory
12 V-B 11.52 V 12.6 V Used with PCI, fans, onboard logic, and audio regulator
12 V-D 11.52 V 12.6 V Used with storage (disk, optical, floppy)
12 V-G 11.52 V 12.6 V Used with PCI Express x16 auxiliary connectors
V12N –11.4 V –12.6 V Used by PCI
5 VSB 4.85 V 5.25 V Used for sleep circuitry and input to onboard regulators
Table 1-6 Current specification
Current Continuous Description
3.3 V 22.0 A Used with PCI, onboard logic, SAS controller, IEEE
1394, and chipset
5 V 18.0 A Used with storage (disk, optical, diskette), PCI,
Audio, USB, input to onboard regulator, and
onboard logic
12 V CPU0 13.7 A Input to onboard regulator that supplies power for
CPU 0
6 Chapter 1 Product overview ENWW
