HP xw9400 User Manual

D System board designators
This appendix lists the system board designators for this system.
Designator Silkscreen Component
BAT1 BAT1 Battery retainer
E15 CRISIS RECOVERY Boot Block recovery jumper
E49 CLR PSWD Clear password jumper
J9 None Stacked RJ45/dual USB
J12 FRNT 1394 Front panel 1394a header
J14 SPDIF OUT connector
J15 None Stacked RJ45/dual USB
J20 SLOT3 PCI32/33 PCI 32–bit slot
J25 SLOT6 PCI-X x100 PCI-X slot
J26 SLOT7 PCI-X x100/133 PCI-X slot
J31 SLOT1 PCI-E x8 PCIe x8 slot
J32 SLOT5 PCI-E x16 PCIe x16 slot
J33 SLOT4 PCI-E x8 PCIe x8 slot
J34 FRNT-P Front panel connector
J41 SLOT2 PCI-E x16 PCI Express x16 slot for graphics
J68 None Stacked keyboard/mouse connector
J83 Triple stacked audio jack
J84 1394/USB IEEE 1394a/dual USB stacked connector
JP13 1-2 FORCE TO100 MHz
2-3 100/133 MHz (DEFAULT)
PCI-X bus speed select jumper*
JP16 HBA HDD LED ACTIVITY HBA HDD LED activity header
JP30 FAN DET OVR Fan detection override jumper
P1 PWR Main power connector (24-pin)
P2 PWR2 Memory power connector (4-pin)
P3 PWRCPU Processor power connector (8-pin)
ENWW 161

HP xw9400 Specifications

General

Chipset	NVIDIA nForce Professional 3600
Form Factor	Tower
Networking	Integrated Gigabit Ethernet
Processor	Dual-Core AMD Opteron 2200 Series or Quad-Core AMD Opteron 2300 Series
Memory	Up to 32 GB DDR2
Storage	SATA or SAS hard drives
Graphics	NVIDIA Quadro or ATI FirePro options
Expansion Slots	Multiple PCI and PCIe slots
Operating System	Windows XP Professional, Windows Vista, Linux
