Page #39 background imageLoading...
Page #39 background image
System Recovery
CAUTION: This procedure will delete all user information. To prevent loss of information, be sure to back up
all user information so you can restore it after recovery.
Always use the System Restore procedure before you use the System Recovery program. See System Restore
on page 30.
System Recovery completely erases and reformats the hard disk drive, deleting all data les that you have
created, and then reinstalls the operating system, programs, and drivers. However, you must reinstall any
software that was not installed on the workstation at the factory. This includes software that came on media
included in the workstation accessory box, and any software programs that you have installed.
You can order a recovery media set from support. For U.S. support, go to http://www.hp.com/support. For
worldwide support, go to http://www8.hp.com/us/en/contact-hp/ww-contact-us.html. You can also order the
recovery media set by calling support.
NOTE: Some features might not be available on systems that are shipped without a Windows operating
system.
You must choose one of the following methods to perform a System Recovery:
Recovery image — Run System Recovery from a recovery image stored on your hard disk drive. The
recovery image is a le that contains a copy of the original factory-shipped software. To perform a
System Recovery from a recovery image, see System Recovery from a recovery partition image
on page 31.
Recovery media — Run System Recovery from recovery media that you have purchased separately.
System Recovery from a recovery partition image
CAUTION: System Recovery deletes all data and programs that you have created or installed.
A Windows system from the HP factory ships with a recovery partition. You can use the recovery partition to
recover the factory operating system.
1. Turn o the workstation. If necessary, press and hold the power button until the workstation turns o.
2. Disconnect all peripheral devices from the workstation except the monitor, keyboard, and mouse.
3. Press the power button to turn on the workstation.
4. As soon as you see the HP logo screen, repeatedly press the F11 key on your keyboard until the Windows
is Loading Files... message appears on the screen.
5. At the HP Recovery Manager screen, follow the on-screen instructions to continue.
6. When Windows has loaded, shut down the workstation, reconnect all peripheral devices, and then turn
the workstation back on.
Backing up, restoring, and recovering Windows 7 31

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z2 Mini G3 and is the answer not in the manual?

HP Z2 Mini G3 Specifications

General IconGeneral
Tcase71 °C
Bus typeDMI3
SteppingR0
Processor cache8 MB
Processor cores4
Processor modeli7-6700
System bus rate8 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-6700 Desktop series
Processor socketLGA 1151 (Socket H4)
Processor threads8
Processor codenameSkylake
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency4 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)65 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory clock speeds supported by processor1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
Product typeWorkstation
Motherboard chipsetIntel® C236
Non-ECCYes
Memory slots2x SO-DIMM
Internal memory16 GB
Memory channelsDual-channel
Memory clock speed2400 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)2 x 8 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfacePCI Express
Storage mediaSSD
Total storage capacity256 GB
On-board graphics card ID1912
Discrete graphics card modelNVIDIA® Quadro® M620
On-board graphics card modelIntel® HD Graphics 530
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1150 MHz
Number of displays supported (on-board graphics)3
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power supply135 W
USB 2.0 ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
Sustainability certificatesENERGY STAR
Chassis typeSmall Desktop
Product colorBlack
Country of originChina
Scalability1S
Processor codeSR2BT
Processor ARK ID88196
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, AVX 2.0, SSE4.2
Thermal solution specificationPCG 2015C
Intel Secure Key Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth216 mm
Width2040 mm
Weight58 g
