HP Z2 Mini G3 User Manual

Using HP Recovery operating system media
CAUTION: Using a Windows 7 operating system USB ash drive completely erases hard drive contents and
reformats the hard drive. All les that you have created and any software that you have installed on the
workstation are permanently removed. When reformatting is complete, the recovery process helps you
restore the operating system, as well as the original drivers. Software that came with the system can be
downloaded at http://www.hp.com.
Use the steps provided in this section if you ordered a Windows 7 operating system and Driver USB ash drive.
To order a Windows 7 operating system and Driver USB ash drive, go to the HP website. For U.S. support, go
to
http://www.hp.com/cgi-bin/hpsupport/index.pl. For worldwide support, go to http://www8.hp.com/us/en/
contact-hp/ww-contact-us.html. You can also order the recovery USB ash drive by calling support.
To initiate recovery using a Windows 7 operating system and driver USB ash drive:
NOTE: This recovery process takes several minutes.
1. Back up all personal les.
2. Restart the workstation, and then insert the Windows 7 operating system and driver USB ash drive into
a USB port.
NOTE: If the workstation does not boot to the USB ash drive, restart the workstation and press Esc as
the workstation is powering on to see the startup menu. Use the arrow keys to select the boot menu and
press Enter. Use the arrow keys to select the location of the USB ash drive to boot from that device.
Booting the USB ash drive from UEFI Boot sources will result in a GPT boot partition. Booting from
Legacy Boot sources will result in an MBR boot partition.
3. When prompted, press any keyboard key.
4. Follow the on-screen instructions.
NOTE: After the operating system installation has completed, you will be allowed to load drivers.
5. Install the Hardware Enabling Drivers. HP recommends installing all available drivers.
6. You can download applications that came with the workstation at http://www.hp.com.
32 Chapter 5 Setting up, backing up, restoring, and recovering Windows 7

HP Z2 Mini G3 Specifications

General

Tcase	71 °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor cores	4
Processor model	i7-6700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6700 Desktop series
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)	65 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
Product type	Workstation
Motherboard chipset	Intel® C236
Non-ECC	Yes
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	256 GB
On-board graphics card ID	1912
Discrete graphics card model	NVIDIA® Quadro® M620
On-board graphics card model	Intel® HD Graphics 530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power supply	135 W
USB 2.0 ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Sustainability certificates	ENERGY STAR
Chassis type	Small Desktop
Product color	Black
Country of origin	China
Scalability	1S
Processor code	SR2BT
Processor ARK ID	88196
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, AVX 2.0, SSE4.2
Thermal solution specification	PCG 2015C
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	216 mm
Width	2040 mm
Weight	58 g
