Each SFP+ port has a status LED to show port operating status and activities.
Table 25 SFP+ port LED description
LED status Description
Steady green
A transceiver module or network cable has been correctly installed. The port
has a link and is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module or network cable has been correctly installed. The port
has a link and is operating at 1 Gbps.
Flashing yellow (3 Hz) The port is sending or receiving data at 1 Gbps.
Off
No transceiver module or network cable has been installed or no link is present
on the port.
Management Ethernet port LEDs
The switch provides two status LEDs LINK and ACT for the copper management Ethernet port and
one double-color LED LINK/ACT for the fiber management Ethernet port.
Table 26 Copper management Ethernet port LED description
LED mark Status Description
LINK
Off No link is present on the port
Steady green The port is operating at 10/100/1000 Mbps.
ACT
Off The port is not receiving or sending data.
Flashing yellow The port is sending or receiving data.
Table 27 Fiber Management Ethernet port LED description
LED mark Status Description
LINK/ACT
Off No link is present on the port.
Steady green The port is operating at 1000 Mbps.
Flashing green The port is receiving or sending data at 1000 Mbps.
Steady yellow The port is operating at 100 Mbps.
Flashing yellow The port is receiving or sending data at 100 Mbps.
Fan tray alarm LEDs
The HPE X712 HV2 fan tray and HPE X711 HV2 fan tray each provide an alarm LED.
Table 28 HPE X712 HV2 fan tray and HPE X711 HV2 fan tray alarm LED description
Status Description
Steady orange The fan tray is faulty.
Off The fan tray is operating correctly or no power is being input.
