5
Installation accessories
Table 4 Installation accessories
Switch
model
Mounting brackets Rack mounting rail kit
HPE
FlexFabric
5950
A pair of 1U mounting
brackets. See Figure 2.
x A pair of 1U long slide rails and one pair of chassis
rails. See Figure 3.
x
(Optional.) A pair of 1U short slide rails and one pair
of chassis rails. See Figure 4.
Figure 2 Mounting brackets for the HPE FlexFabric 5950 switch
Figure 3 1U long slide rail and chassis rail
(1) Chassis rail (2) Long slide rail
Figure 4 1U short slide rail and chassis rail
(1) Chassis rail (2) Short slide rail
1 2
