HPE OfficeConnect 1950 12XGT 4SFP+

30
Appendix B Ports and LEDs
Ports
Console port
The switch has two console ports: a serial console port and a mini USB console port.
Table 11 Console port specifications
Item
Serial console port
Mini USB console port
Connector type
RJ-45
Mini USB-Type B
Compliant standard
EIA/TIA-232
USB 2.0
Transmission baud rate
9600 bps (default) to 115200 bps
Services
 Provides connection to an ASCII
terminal.
 Provides connection to the serial port
of a local or remote (through a pair of
modems) PC running terminal
emulation program.
Provides connection to the USB port
of a local PC running terminal
emulation program.
Management Ethernet port
Each switch provides a management Ethernet port on the front panel. You can connect the
management Ethernet port to a PC or management station for loading and debugging software or
remote management.
Table 12 Management Ethernet port specifications
Item
Specification
Connector type
RJ-45
Port transmission rate
10/100 Mbps, half/full duplex
1000 Mbps, full duplex
MDI/MDI-X auto-sensing
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Standards
IEEE 802.3i, 802.3u, 802.3ab
Functions and services
Switch software and Boot ROM upgrade, network management
1/10GBASE-T autosensing Ethernet port
Each switch provides 12 fixed 1/10GBASE-T autosensing Ethernet ports on the front panel.
