HPE OfficeConnect 1950 12XGT 4SFP+ User Manual

31
Table 13 1/10GBASE-T autosensing Ethernet port specifications
Item
Specification
Connector type
RJ-45
Interface attributes
1/10 Gbps, full duplex, MDI/MDI-X auto-sensing
Max transmission
distance
 Category-6 UTP—55 m (180.45 ft)
 Category-6 STP—100 m (328.08 ft)
 Category-6 SFTP—100 m (328.08 ft)
 Category-6 and above twisted pair—100 m (328.08 ft)
Transmission medium
Category-6 (or above) twisted pair cable
Standards
IEEE 802.3ab, 802.3an
SFP+ port
Each switch provides 4 fixed SFP+ ports on the front panel. To connect the peer SFP+ ports over a
long distance, use SFP/SFP+ transceiver modules and fibers. To connect the peer SFP+ ports over
a short distance, use SFP+ cables. You can install the 1000 Mbps SFP transceiver module in Table
14, 10 Gbps SFP+ transceiver modules in Table 15, or 10 Gbps SFP+ network cables in Table 16 in
the SFP+ ports.
Table 14 1000 Mbps SFP transceiver modules available for the SFP+ ports
Product
code
HPE
description
Central
waveleng
th (nm)
Conn
ector
Cable/fiber
diameter
(µm)
Multimode
fiber
modal
bandwidth
(MHz × km)
Max
transmission
distance
JD089B
HPE X120 1G
SFP RJ45 T
Transceiver
N/A
RJ-45
Category-5
twisted pair
N/A
100 m (328.08 ft)
JD118B
HPE X120 1G
SFP LC SX
Transceiver
850
LC
Multi-mode,
50/125
500
550 m (1804.46 ft)
400
500 m (1640.42 ft)
Multi-mode,
62.5/125
200
275 m (902.23 ft)
160
200 m (656.17 ft)
JD119B
HPE X120 1G
SFP LC LX
Transceiver
1310
LC
Single-mode
, 9/125
N/A
10 km (6.21 miles)
Multi-mode,
50/125
500 or 400
550 m (1804.46 ft)
Multi-mode,
62.5/125
500
550 m (1804.46 ft)
JD061A
HPE X125 1G
SFP LC LH40
1310nm
Transceiver
1310
LC
Single-mode
, 9/125
N/A
40 km (24.86
miles)
JD062A
HPE X120 1G
SFP LC LH40
1550nm
Transceiver
1550
LC
Single-mode
, 9/125
N/A
40 km (24.86
miles)
