Fan locations
Item Description
1 Default system fan
2 Default PCI fan
The server also supports the Redundant fan option kit.
Fan mode behavior
• In nonredundant fan mode, a fan failure or a missing fan causes:
â—¦ The system Health LED to flash amber.
â—¦ The operating system to orderly shutdown.
• In redundant fan mode:
â—¦ A fan rotor failure will switch the system to nonredundant fan mode.
This change is indicated by the Health LED flashing amber. The system continues to operate normally in this
mode.
â—¦ A second fan rotor failure or a missing fan causes the operating system to orderly shutdown.
Component identification
22
