System maintenance switch descriptions
Position Default Function
S1
1
Off
Off = iLO security is enabled.
On = iLO security is disabled.
S2 — Reserved
S3 Off Reserved
S4 Off Reserved
S5
1
Off
Off = Power-on password is
enabled.
On = Power-on password is
disabled.
S6
1, 2
Off
Off = No function
On = Restore default
manufacturing settings
S7 — Reserved
S8 — Reserved
S9 — Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
1
You can access the redundant ROM by setting S1, S5, and S6 to On.
2
When the system maintenance switch position 6 is set to the On position, the system is prepared to
restore all configuration settings to their manufacturing defaults.
When the system maintenance switch position 6 is set to the On position and Secure Boot is enabled,
some configurations cannot be restored. For more information, see Secure Boot configuration.
Bayonet board components
1U bayonet board
10 System maintenance switch descriptions
