FlexibleLOM 1U riser
Item Form Factor Slot number Description
1 FlexibleLOM FlexibleLOM slot PCIe3 x16 for Processor 1
2 Slimline SAS cable for NVMe
support
— Port 1
1
1
Not shown
1U secondary riser for processor 1
Item Form Factor Slot number Description
1 — — Storage backup power connector
2 Storage controller or low-profile
PCIe expansion board
2 PCIe3 x16 (16, 8, 4, 1) for Processor
1
3 Slimline SAS cable for NVMe
support
— Port 1
1
12 FlexibleLOM 1U riser
