Installed in HPE Apollo r2800 Gen10 Chassis with 16 NVMe
SUV cable connectors
CAUTION: Before disconnecting the SUV cable from the connector, always squeeze the release
buttons on the sides of the connector. Failure to do so can result in damage to the equipment.
NOTE: If all server tray slots in the chassis are populated with servers, connect a SUV cable for
maintenance purposes only.
Item Connector Description
1 Serial For trained personnel to connect a null modem serial cable
and perform advanced diagnostic procedures
2 USB
1
For connecting up to two USB 2.0 devices
3 Video For connecting a video monitor
SUV cable connectors 71
