Procedure
1. Back up all server data.
2. Power down the server.
3. Remove the server from the chassis.
4. Remove the air baffle.
5. If a secondary PCI riser cage is installed, remove the bayonet board.
6. Do one of the following:
• Remove the secondary PCI riser blank.
• Remove the secondary PCI riser cage.
7. Remove the expansion slot blank.
8. If installed, remove the full-height bracket from the expansion board.
Hardware options installation 47
