Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―97―
6.2.19 Group F18 Display Control Parameters
Note: Refer to the User Manual of HD30-WIO about water and wastewater applications.
No. Name Description Range
factory setting
F18.00 Language selection 0,1
0
It defines the displaying language on the LCD display panel.
• Only when using LCD display panel will F18.00 be enabled.
0: Chinese.
1: English.
F18.01 Displaying contrast of the LCD display panel 1
10
5
To select LCD displaying contrast.
• Only when using LCD display panel will F18.01 be enabled.
F18.02 Set the display parameter 1 during operation 0
49
7
Set the display parameter 2 during operation
F18.04 Set the display parameter 3 during operation 0
49
9
Set the display parameter 4 during operation
F18.06 Set the display parameter 5 during operation 0
49
14
Set the display parameter 6 during operation
F18.08 Set the display parameter 1 at stop 0
49
7
Set the display parameter 2 at stop
F18.10 Set the display parameter 3 at stop 0
49
20
Set the display parameter 4 at stop
F18.12 Set the display parameter 5 at stop 0
49
43
Set the display parameter 6 at stop
The display panel displays parameters which difine the operation status (F18.02－F18.07) and stop
status (F18.08－F18.13).
• It can be cycling displayed by key on the display panel.
• Each display parameter of content can be set as the corresponding 49 statuses.
• For instance: when set F18.08 as 7, it displays stop parameters which is setting frequency at initial
power on.
0: Reserved.
1: Inverter’s rated current.
2: Inverter’s extension function.
• 0: No extension function.
• 1: Water and wastwater applications.
3: The inverter status is shown as below table:
Bit3 Bit2 Bit1 Bit0
Units Zero-frequenc
y operation
Forward/ Reverse Run/ Stop Inverter fault
Tens DC braking Reserved Bit1&Bit0: Acceleration/ Deceleration/
Constant speed
Hundreds Reserved Speed limitation Reserved auto-tuning
Thousands Reserved Reserved Stall overcurrent Stall overvoltage
4: Master setting frequency source.
5: Master setting frequency.
6: Auxiliary setting frequency.
6
