2.3 Specifications
Item Specification
Electrical
Rated voltage and
frequency
Single/three-phase: 200－240V, 50/60Hz
Three-phase: 380－460V, 50/60Hz
Accuracy
Voltage: fluctuating within ± 10%, imbalance rate < 3%
Frequency: ± 5%
Output voltage
Three-phase: 0－240V
Three-phase: 0－460V input voltage
Output frequency 0－400.00Hz
Performance
Maximum current
150% rated output current for 2 minutes
180% rated output current for 10 seconds
Control mode Open-loop vector control; V/f control
Operation command
setting mode
Display panel setting; external terminal setting; host computer
communication setting via SCI communication port
Speed setting mode Digital setting, analogue setting, SCI communication setting
Speed setting
resulotion
Digital setting: 0.01Hz
Analogue setting: 0.1% × max-frequency
Speed control
accuracy
Open-loop vector control: ± 0.5%
Speed control range Open-loop vector control: 1:100
Torque control
response
Open-loop vector control: < 200ms
Start torque Open-loop vector control: 180% rated-torque /0.5Hz
Torque control
accuracy
±5%
Characteristic
User-definable menu Total 16 user-definable maps, user can edit
Multi-group parameter
upload and download
function
To achive 2 group parameters uploading to display panel of backup
function
Programmable I/O
interface
Input interface programmable is up to 53 functions
Output interface pragrammable is up to 38 functions
Process PID
adjustment
Internal process PID module
Simple PLC
To achive time and multi-frequency output with internal simple PLC
module
Wobble operation Internal wobble operation module
Fixed length control Internal fixed length control module
Water and
wastewater
applications
Internal water and wastewater applications module which should be with
HD30-WIO
Compatible
multi-communication
protocol
Inverter built-in MODBUS communication protocol.
Available options:
PROFIBUS bus module, compatible with PROFIBUS protocol;
DeviceNet bus module, compatible with DeviceNet protocol;
