MONT30 Starting Guide V1.0
13
5.2 Motor Self-learning
Asyn. Motor Selt-learning Operation
1. Use the keypad to set parameters, see below or section 5 .1. 3 .
•
Control parameters: F00.02 (OD and CD mode), F00.06 (motor control mode).
•
Motor parameters: F01.0 0 - F01.04, F01.05 (reduction ratio) needs to be set for distance
control.
•
Encoder parameters need to be set for distance control: F02.00 - F02.01.
2.
Set DIP switch S1&S2 = ON&ON, press Button for 1s and release button, the door controller
starts motor self-learning.
The indicator is flashing green.
3.
When the indicator does not flash, the self-learning ends, the door controller automatically
records F01.07, F01.09 - F01.13.
If the indicator is always on (red), the self-learning fails. Take measures: Use the keypad to
confirm the fault, clear the fault, and start motor self-learning again until success.
Syn. Motor Selt-learning Operation
Do not remove the belt, fully close the door manually.
2. Use the keypad to set parameters, see below or section 5 .1. 3 .
•
Control parameters: F00.02 (OD and CD mode), F00.06 (motor control mode).
•
Motor parameters: F01.00 - F01.05.
•
Encoder parameters: F02.00 - F02.01.
3.
Set DIP switch S1&S2 = ON&ON, press Button for 1s and release button, the door controller
starts motor self-learning.
The indicator is flashing green. The door moves in the OD direction. When the self-learning
ends, the door automatically stops moving.
If the door does not open, and the door controller report encoder fault. Take measures: Stop,
change DIP switch S4, and start motor self-learning again.
4.
When the indicator does not flash, the self-learning ends, the door controller automatically
records F01.08 - F01.13.
If the indicator is always on (red), the self-learning fails. Take measures: Use the keypad to
confirm the fault, clear the fault, and start motor self-learning again until success.
5. If the encoder is ABZ, record F01.08 (pole angle).
Start self-learning again and record F01.08, the difference between the two F01.08 is less than
30°. Otherwise, need to find out the reason, and start self-learning again.
