MONT30 Starting Guide V1.0
14
5.3 Door Width Self-learning (Only Distance Control)
Only in distance control, door width self-learning is needed, learn the door width.
1. Confirm the door movement path is clear of obstacles.
2.
Set
DIP switch S1&S2 = OFF&ON
, press
Button
for 1s and release button, the door controller
starts door width self-learning.
3.
Confirm the the door action sequence is correct, check d01.00 to confirm the OD/CD pulse
signal is correct (keypad), as shown in the figure below.
After the end, F02.07 and F02.08 record the door width.
If abnormality occurs during self-learning, stop (wait for MONT30 to stop automatically), clear
the abnormality, and start door self-learning again.
Exception handling:
1. The door move in the CD direction at start.
Take measures: Stop (wait for MONT30 to stop automatically), change DIP switch S4, and start
door width self-learning again.
2. During self-learning, the OD pulses decreases and the CD pulses increases.
Take measures
: Change the setting of F02.02 (encoder direction).
3. During self-learning, the door controller reports E26 fault (door width self-learning fault).
Take measures: Check the encoder signal. For heavy doors, increase F05.14 (OD/CD switch
torque at low speed).
4. When the Asyn. motor is self-learning, the door controller shakes and then stops.
Possible reasons: F02.01 (encoder pulses), F02.02 (encoder direction), F01.05 (reduction ratio)
are incorrectly set.
Ope
n do
or
(OD)
Open door
(OD)
Pulse
increase
Pulse
decrease
Door close
arrived (DCA)
Door close
arrived (DCA)
Close door
(CD)
Close door
(CD)
Door open
arrived (DOA)
Door open
arrived (DOA)
