hpmont MONT30 User Manual

MONT30 Starting Guide V1.0
1
1. Check Product
Check model: Consistent with the ordered model.
Check appearance: The product packaging and appearance is not damaged.
1.1 Model
Code Description
1 Product series
•
MT30
: MONT30 door controller
2
Product
configuration
•
5A-EN: ABZ encoder, power supply 5V
•
IN: High bus voltage
1.2 Layout
M T
3 0
-5A
1 2
Knob
Adjust speed
and torque
Button
DIP switch
S1, S2, S3, S4
ON, OFF
QR code
Scan QR to get the
bluetooth APP
Power Switch
ON, OFF
Nameplate
Barcode
OTA
Upgrade software
RJ45
External keypad
Power terminal
Plug type
CAN communication
terminal
Plug type
Control terminal
Plug type
Encoder terminal
Plug type
Indicator
YL: Yellow
GN: Green
RD: Red

hpmont MONT30 Specifications

General

Brand	hpmont
Model	MONT30
Category	Controller
Language	English
