HSD ES327 - Page 101

8 Replacing components
HSD S.p.A. © - 0108h02a.fm100713
101
ES370
Figure 17
S1 sensor S1
S4 sensor S4
1 screws
2 washer
e
eccentricity between the
nut and sensor, for
adjustment
L calibrated position
3 Sensor
4 nut
5 electric connector
S4
S1
2
1
e
L
5 3
3
4
