5.1.3 Electrical circuit
5.1.4 Inverter programming
The maximum voltage set on the inverter must correspond to the rated value indicated on the
motor rating plate.
The set frequency value at which the voltage becomes maximum (rated frequency) must
correspond to the rated value indicated on the motor rating plate.
The maximum speed set on the inverter must correspond to the value indicated on the motor
rating plate.
The maximum continuous current set on the inverter must correspond to the rated current
value indicated on the motor rating plate.
Contact the manufacturer if it is considered necessary to check the other parameters of the
inverter.
5.2 First start-up checks
The tool holder cone ejection progress must be that specified in section 6.5 “Tool holder
locking and ejection device”.
The control sensors must intervene according to the logic described in section 6.8.
The tool change cycle must only take place with the shaft stopped.
with the tool holder inserted and without performing machining operations, perform the
preheating cycle described in section 6.3.
The earth of the product (indicated in section 4.9 “Electronic connections for
models with free cables”) must be connected to the earth of the machine;
the thermal safety must trigger an overheating protection procedure of the
electrospindle coils (see section 4.8 ).
Only switch on the electrospindle if the sensors S1 for models ISO or S1+S4 for
models HSK (where present) are “ON” (tool holder coupled)
The sensor “ON” condition corresponds to an output equal to the power supply
voltage.
The sensor “OFF” condition corresponds to an output of 0 V.
Only for HSK models:
The electrospindle must not be started without the tool holder inserted.
The cylinder of the ES330 electrospindle is double acting: the cylinder must be
kept under pressure to hold the piston on the upper limit switch, away from
fast-rotating parts.
