2 Technical Specifications
HSD S.p.A. © - 0102h00a.fm100713
33
ES 330 220V AIR
Rated voltage V 220 220 220 220
Rated frequency Hz 400 500 600 800
Rated speed rpm 12000 15000 18000 24000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
4 4.5 4 4.5 3.7 4.1 2.5 2.6
Rated torque Nm
3.2 3.8 2.5 3 1.7 2.3 1 1.2
Rated current A
16 19 16 19.2 15 20.3 11.5 14
Rated efficiency 0.85
Power factor cos 0.7
Number of poles 4
Insulation class F
Cooling Electric fan
Weight Kg 15
IP level 50
The maximum rated current "S1/cont" is used to set the "maximum continuous
current" parameter of the inverter.
