HSD ES327 - Weight Kg

2 Technical Specifications
HSD S.p.A. © - 0102h00a.fm100713
41
ES 370 380V
Rated voltage V 380 380 380 380
Rated frequency Hz 350 600 1000 1200
Rated speed rpm 10500 18000 30000 36000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
10.5 12.6 10.5 12.6 6 7.2 3.9 4.5
Rated torque Nm
9.5 11.5 5.6 6.7 1.9 2.3 1 1.2
Rated current A
22.1 26.7 22 26.7 13 15.7 7.4 8.9
Rated efficiency 0.85
Power factor cos 0,74
Number of poles 4
Insulation class F
Cooling Liquid
Weight Kg
IP level 54
The maximum rated current "S1/cont" is used to set the "maximum continuous
current" parameter of the inverter.
