2 Technical Specifications
18
HSD S.p.A. © - 0102h00a.fm100713
1 Air inlet for tool locking -
8/6 mm - hole 1/8”G
2 Air inlet for tool change and cone cleaning-
8/6 mm - hole 1/8”G
3 Cylinder area
4 Rear casing
5 2 rest surfaces (yellow area and opposite side of electric connector)
6 2 holes
8 mm H9 , 10 mm depth
7 6 holes M8 mm H9, thread depth of 12 mm
8 Tool holder description
9 Cooling air outlet channels
10 Electrospindle "nose"
11 Labyrinth with pressurisation
12 Coupling system ISO30 ( "collet” )
13 Cooling air inlet grid (electric fan)
14 Power wiring outlet- cable clamp M25x1.5
15 Signal wiring outlet- cable clamp M16x1.5
16 Electric flying female connector (“flying mounting plate”)
17 EC plate
18 Fixed male electronic connector (“fixed mounting plate”)
19 Button for tool release manual command
20 Serial number
21 Casing
22 Shaft
