2 Technical Specifications
22
HSD S.p.A. © - 0102h00a.fm100713
1 Power/signal wiring outlet- n. 2 cable clamps (1xM12 + 1x)
2 Sensor compartment cover
3 Electrospindle "nose"
4 Labyrinth with pressurisation
5 Coupling system ISO30
6 Spindle shaft
7 Front flange
8 Casing (sensors area)
9 Electrospindle casing
10 Pneumatic cylinder area
11 Pneumatic and hydraulic joins
12 Serial number
