HTC One X User Manual

Title hardware Remove SIM - microSIM - slide tray - eject tool angle
Identifier GUID-4E4D897D-E125-4026-85F2-7401254197B0
Version 4
Removing the SIM card
Make sure to switch off HTC One X before removing your SIM card.
1. Hold HTC One X face down and the top panel facing you.
2. Insert the tip of the SIM eject tool (or a small bent paperclip) into the small hole
next to the SIM card tray slot. You should insert it at an angle.
3. Push the tip all the way into the hole until the SIM card tray ejects.
4. Pull the SIM card tray out.
5. Take the SIM card from the SIM card tray.
11 Unboxing

HTC One X Specifications

General

Processor	Quad-core 1.5 GHz Cortex-A9
RAM	1 GB
Storage	32 GB
Front Camera	1.3 MP
Operating System	Android 4.0 (Ice Cream Sandwich), upgradable to 4.2.2 (Jelly Bean)
Dimensions	134.4 x 69.9 x 8.9 mm
Weight	130 g
SIM	Micro-SIM
Screen Protection	Corning Gorilla Glass 2
Video	1080p@30fps
Loudspeaker	Yes, with stereo speakers
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band, DLNA, hotspot
GPS	Yes, with A-GPS
NFC	Yes
Radio	Stereo FM radio, RDS
USB	microUSB 2.0 (MHL TV-out)
Sensors	Accelerometer, gyro, proximity, compass
Display	4.7 inches, 720 x 1280 pixels
Rear Camera	8 MP, f/2.0, 28mm
Battery	Non-removable Li-Po 1800 mAh
GPU	ULP GeForce
Bluetooth	4.0, A2DP
Colors	White, Gray
