Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
100
Table 3-68 Technical specifications of an alarm beacon
Item
Specifications
Power input
RJ45 port, input voltage 9–16 V DC, operating current ≤ 400
mA
Sound pressure
≥ 100 ± 3 dB/30 cm
Continuous operating
time
≥ 45 min
3.4.16 PAD
The PAD allows the wireless access from the data center management system. You can
monitor the equipment in the data center and environmental parameters in real time over the
APP
Figure 3-70shows a PAD.
Figure 3-70 PAD
The PAD used in the micro-module is a capacitive touchscreen that supports multi-touch
technology. Table 3-69lists the PAD structural specifications.
Table 3-69 PAD structural specifications
Item
Specifications
Dimensions (L x W x
H)
248.5 mm x 150 mm x 8.3 mm
Weight
About 433 g
