3.1.3 IT Cabinet
IT cabinets of the Smart Module comply with the International Electrotechnical Commission
(IEC) 60297-1 standard, provide stable installation space for servers in the Smart Module, and
ensure secure server running.
The cabinets have the uniform dimensions and provide front and rear ventilation channels.
Figure 3-5shows the cabinet exterior. Table 3-1 lists the technical specifications.
Figure 3-5 IT cabinet appearance
An IT cabinet has the following features:
⚫
The ventilation rate of the front and rear doors is greater than or equal to 70%.
⚫
Two power distribution units (PDU2000s) can be vertically installed at the rear inside the
cabinet.
⚫
The position of each U is marked on the vertical mounting bars.
⚫
The front and rear doors of the cabinet can be locked, and can be unlocked only by using
dedicated keys.
⚫
The cabinet has a door status sensor or electronic access control.
