FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
No system alarm is generated.
Communication
status indicator
No network parameters exist, or a
network is to be created.
Blinking at
long intervals
A network is set up, and no node
access is allowed (the indicator
blinks at 0.5 Hz, on for 1s and then
off for 1s).
Blinking at
super short
intervals
A network is set up, and node
access is allowed (the indicator
blinks at 10 Hz, on for 0.05s and
then off for 0.05s).
Blinking
intermittently at
super short
intervals
The multi-functional sensor is
searching for a network (the
indicator blinks at super short
intervals for 0.5s and then turns off
for 0.5s).
3.4.12 Rack Environment Unit
The rack environment unit collects and controls the environmental data of IT cabinets in the
modular data center. Figure 3-66 shows a rack environment unit.
Figure 3-66 Rack environment unit
(2) 48 V DC power input
port
