FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
Specifications
Table 3-61 lists the environment specifications for the rack environment unit.
Table 3-61 Technical specifications for the rack environment unit
Phoenix terminal, with input voltage of 36–60 V DC
Two 12 V DC power outputs with the rated output current of 250 mA
⚫
FE communication with the rate of 10/100M
⚫
36–60 V DC power input
RS485 serial
port
expansion
⚫
Four RS485 ports with the default communications rate of 9600 bit/s
⚫
Among the four RS485 ports, two support 12 V DC, 400 mA power
output.
⚫
The other two are isolated, with the default communications rate of
9600 bit/s, and do not support power output.
Two active 12 V DC, 200 mA AI/DI input ports
Provides two RJ45 ports to connect to six temperature sensors, each RJ45
port connecting to three temperature sensors.
Indicators
Table 3-62 lists the structural specifications for the rack environment unit.
Table 3-62 Indicator description
Power input
status indicator
The power input is normal.
Module
running status
indicator
The power is abnormal or the board
program is loading.
Blinking at
long intervals
The software runs properly (the
indicator blinks at 0.5 Hz, on for 1s
and then off for 1s).
Blinking at
short intervals
PoE communication fails (the
indicator blinks at 4 Hz, on for
0.125s and then off for 0.125s).
