Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
61
Item
NetCol5000-C030H7A201E12
0E0
NetCol5000-C030H7A201002
0E1
Power system
208 V to 240 V, 1 Ph, 50 Hz/60
Hz
208 V rated voltage tolerance:
–10% to +6%, 220 V and 240 V
rated voltage tolerance: –10% to
+10%, rated frequency
tolerance: ±3 Hz, one active
power supply, and one standby
power supply
208 V to 240 V, 1 Ph, 50 Hz/60
Hz
208 V rated voltage tolerance:
–10% to +6%, 220 V and 240 V
rated voltage tolerance: –10% to
+10%, rated frequency tolerance:
±3 Hz, one active power supply,
and one standby power supply
Fan type
EC fan
EC fan
Speed adjustment
Stepless
Stepless
Rated air volume
5100 m
3
/h
5100 m
3
/h
Maximum
operating pressure
1.6 MPa
1.6 MPa
Configuration of a
condensate pump
No
Yes
Configuration of an
air deflector
No
No
Heating function
Yes
No
Humidification
function
Yes
No
External
dimensions (H x W
x D)
2000 mm x 300 mm x 1000 mm
2000 mm x 300 mm x 1000 mm
Package
dimensions (H x W
x D)
2200 mm x 760 mm x 1350 mm
2200 mm x 760 mm x 1350 mm
Net weight
≤ 171 kg
≤ 165 kg
Installation mode
On a concrete or ESD floor
On a concrete or ESD floor
Certification
RoHS and REACH
RoHS and REACH
a refers to the test condition (return air dry/wet bulb temperature: 37.8°C/20.8°C; chilled
water inlet temperature: 10°C; water flow rate: 5.5 m
3
/h).
3.3.2.4 Performance Curves
Figure 3-43 and Figure 3-44 respectively show the cooling capacity derating coefficient curve
in proportion to the altitude and the cooling capacity curve in proportion to the glycol solution
density when the NetCol5000-C works under rated power and air flow.
