FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
90
Figure 3-63 Smoke detector
Table 3-57 Technical specifications of a smoke detector
Item
Specifications
Operating voltage
9–16 V DC
Quiescent current
< 8 mA
Alarm current
< 35 mA
Output mode
Relay output
Output contact capacity
3 A/120 V AC or 3 A/24 V DC
Operating temperature
–10ºC to +50ºC
Ambient humidity
≤ 95% RH
Dimensions
Diameter: 112 mm, height: 41 mm
3.4.10 (Optional) Temperature Sensor
Figure 3-64 shows a temperature sensor.
Figure 3-64 Temperature sensor
