Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
106
Indicat
or
Col
or
Name
Status
Description
Blinking at
super short
intervals
A network is set up, and node
access is allowed (the indicator
blinks at 10 Hz, on for 0.05s and
then off for 0.05s).
Blinking
intermittently
at super short
intervals
The AC actuator is searching for a
network (the indicator blinks at
super short intervals for 0.5s and
then turns off for 0.5s).
3.6.2 Aisle Lights
Light emitting diode (LED) lights are used in aisles. LED lights are installed on the top at
both ends of the aisles.
Figure 3-75shows an LED light.Table 3-76 lists the technical specifications of an LED light.
Figure 3-75 LED light
Table 3-76 Technical specifications of an LED light
Item
Specifications
Installation mode
Ceiling-mounted
Light holder requirement
The light holder and light are integrated
Protection level
IP20
Electric insulation class
Class I
Standards compliance
IEC 598
Rated operating voltage
220–240 V AC (working normally in the
range of 176 V AC to 288 V AC)
Light color
Daylight color
Luminous flux
≥ 500 lx
Service life
≥ 30,000 hours
Power
12–16 W
