Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
73
Figure 3-50 S5320 LAN switch
Table 3-42 describes parameters of the S5320 LAN switch.
Table 3-42 Parameters of the S5320 LAN switch
Item
Parameter
Dimensions (H x W x D)
44.4 mm x 442 mm x 420 mm
Maximum power consumption (fully
configured)
913 W (Power consumption: 173 W; PoE:
740 W)
Weight
≤ 8 kg
DC input voltage
Rated voltage: -48 V DC to -60 V DC
Voltage range: -36 V DC to -72 V DC
AC input voltage
Rated voltage: 100-240 V AC
Voltage range: 90-264 V AC
Temperature
⚫
Operating temperature: 0°C to +50°C
NOTICE
When the altitude ranges from 1800 m to 5000
m, the highest temperature decreases by 1°C for
each additional 220 m.
⚫
Storage temperature: -40°C to +70°C
Relative humidity
5%-95% RH, non-condensing
Altitude
⚫
Non-PoE device:
− With DC power: 0–2000 m
− With AC power: 0–5000 m
⚫
PoE device: 0–5000 m
3.4.5 Video System
The video system consists of the camera and VCN500, implementing real-time monitoring,
video recording, and playback.
3.4.5.1 IP Camera
The existing network is equipped with the ECC800 that supports the Dynamic Host
Configuration Protocol (DHCP). After the ECC800 and IPC6325 camera are powered on, the
IPC6325 camera automatically obtains an IP address that is in the same network segment as
