FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
⚫
Static load: 1500 kg
Table 3-1 Cabinet technical specifications
⚫
2000 mm x 600 mm x 1100 mm
⚫
2000 mm x 600 mm x 1200 mm
⚫
2000 mm x 800 mm x 1100 mm
⚫
2000 mm x 800 mm x 1200 mm
⚫
2200 mm x 600 mm x 1200 mm
⚫
2200 mm x 800 mm x 1200 mm
High-intensity class A carbon cold rolled steel sheet and zinc-coated
steel sheet
Front and rear ventilation channels
⚫
A 2000 mm high cabinet provides 42 U installation space.
⚫
A 2200 mm high cabinet provides 47 U installation space.
⚫
The distance between the front and rear mounting bars can be
adjusted for every 25 mm.
− For a 1200 mm deep cabinet: The maximum depth for
installing devices inside the cabinet is 750 mm and by
adjusting the mounting bars the maximum depth is 850 mm.
− For a 1100 mm deep cabinet: The maximum depth for
installing devices inside the cabinet is 700 mm and by
adjusting the mounting bars the maximum depth is 750 mm.
⚫
Positions for vertically installing two PDU2000s are provided at
the rear of the cabinet.
ESD floor, base, or concrete floor
The front door is a single door, and the rear door is a double one.
Weight of an empty
cabinet
⚫
The weight of a 2000 mm x 600 mm x 1200 mm cabinet is 128
kg.
⚫
The weight of a 2000 mm x 800 mm x 1200 mm cabinet is 153
kg.
⚫
The weight of a 2200 mm x 600 mm x 1200 mm cabinet is 137
kg.
⚫
The weight of a 2200 mm x 800 mm x 1200 mm cabinet is 164
kg.
⚫
The weight of a 2000 mm x 600 mm x 1100 mm cabinet is 110
kg.
⚫
The weight of a 2000 mm x 800 mm x 1100 mm cabinet is 135
kg.
(The weight of an empty cabinet includes the weight of the front and
rear doors.)
