Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
50
Indicator
Color
Meaning
Status
Description
Measure
ALM
Red
Alarm indicator
Steady
on
The actual
number of
online devices is
less than the
value of BIM
number.
Check the value
of BIM number,
the BIM cable
connection, and
the BIM
indicators.
Off
The actual
number of
online devices
equals the value
of BIM number.
Requires no
handling.
PWR
Green
Power indicator
Steady
on
Board power
indicator.
Requires no
handling.
⚫
If an indicator blinks at long intervals, it is blinking at 0.5 Hz, that is, on for 1s and then off for 1s.
⚫
If an indicator blinks at short intervals, it is blinking at 4 Hz, that is, on for 0.125s and then off for
0.125s.
⚫
If an indicator blinks at super short intervals, it is blinking at 10 Hz, that is, on for 0.05s and then off
for 0.05s.
⚫
Blinking intermittently at super short intervals means an indicator blinks at super short intervals for
0.5s and then remains off for 0.5s.
Networking Switch
Table 3-26 Networking switch description
Name
Definition
Function
Button pressing
Press the button for
less than 1s.
CIM blinking function
Button pressing
Press and hold the
button for more than
1s but less than 5s.
Creates a network if no network has
been created. Switches between network
organization and data transmission if a
network has been created.
Button holding down
Press and hold the
button for more than
10s but less than 20s.
Clears the current network (including
the network parameters of all the online
BIMs).
Default Button
Table 3-27 Default button description
Name
Definition
Function
