Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
59
Item
NetCol5000-C030H6B2010020
E1
NetCol5000-C030H6B201002
0E0
External
dimensions (H x W
x D)
⚫
2000 mm x 300 mm x 1000
mm
⚫
2000 mm x 300 mm x 1200
mm
⚫
2000 mm x 300 mm x 1000
mm
⚫
2000 mm x 300 mm x 1200
mm
Package
dimensions (H x W
x D)
2200 mm x 760 mm x 1350 mm
2200 mm x 760 mm x 1350 mm
Net weight
≤ 165 kg
≤ 166 kg
Installation mode
On ESD floor
On ESD floor
Certification
RoHS and REACH
RoHS and REACH
a refers to the test condition (return air dry/wet bulb temperature: 37.8°C/20.8°C; chilled
water inlet temperature: 10°C; water flow rate: 5.5 m
3
/h).
Table 3-34 NetCol5000-C technical specifications (2)
Item
NetCol5000-C030H7B201E12
0E0
NetCol5000-C030H7B2010020
E1
Cooling capacity
30 kW
a
30 kW
a
Maximum power
⚫
Active route: 7050 W
⚫
Standby route: 1200 W
1200 W
Maximum current
⚫
Active route: 26 A
⚫
Standby route: 6.5 A
6.5 A
Air supply mode
Horizontal flow
Horizontal flow
Power system
208 V to 240 V, 1 Ph, 50 Hz/60
Hz
208 V rated voltage tolerance:
–10% to +6%, 220 V and 240 V
rated voltage tolerance: –10% to
+10%, rated frequency
tolerance: ±3 Hz, one active
power supply, and one standby
power supply
208 V to 240 V, 1 Ph, 50 Hz/60
Hz
208 V rated voltage tolerance:
–10% to +6%, 220 V and 240 V
rated voltage tolerance: –10% to
+10%, rated frequency tolerance:
±3 Hz, one active power supply,
and one standby power supply
Fan type
EC fan
EC fan
Speed adjustment
Stepless
Stepless
Rated air volume
5100 m
3
/h
5100 m
3
/h
Maximum
operating pressure
1.6 MPa
1.6 MPa
