Huawei FusionServer Pro 2288H V5 - Pcie Slot Description

Figure 2-47 PCIe riser module 6
2.7.3 PCIe Slot Description
The PCIe slots mapping to a vacant CPU socket are unavailable.
Table 2-15 PCIe slot description
PCIe
Slot
CPU PCIe
Standa
rds
Conne
ctor
Width
Bus
Width
Port
No.
Root
Port
(B/D/F
)
Device
(B/D/F
)
Slot
Size
RAID
controll
er card
CPU 1 PCIe
3.0
x8 x8 Port1C 17/02/0 1D/
00/0
-
LOM CPU 1 PCIe
3.0
x8 x8 Port1A 17/00/0 1A/
00/0
-
FlexIO
card
CPU 2 PCIe
3.0
x8 x8 Port2A AE/
00/0
AF/
00/0
-
FusionServer Pro 2288H V5 Server
User Guide
2 Hardware Description
Issue 08 (2019-10-30) Copyright © Huawei Technologies Co., Ltd. 45
