No. Data
1 Number of the incoming interface and outgoing interface of packets
2 VLAN ID and 802.1p priority of the incoming interface before VLAN stacking is
configured
3 VLAN ID and internal priority of the incoming interface after VLAN stacking is
configured
4 Internal priority of the outgoing interface before VLAN mapping is configured
5 802.1p priority of the outgoing interface before VLAN mapping is configured
5.6.2 Configuring VLAN Stacking Based on the VLAN Priority on
the Incoming Interface
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
interface interface-type interface-number
The interface view is displayed.
Step 3 Run:
port hybrid untagged vlan vlan-id
The interface is added to the VLAN specified by vlan-id.
Step 4 Run the following commands as required.
l To configure VLAN stacking based on the VLAN priority on the incoming interface, run
port vlan-stacking 8021p 8021p-value stack-vlan vlan-id.
l To configure VLAN stacking based on the VLAN ID and VLAN priority on the incoming
interface, run port vlan-stacking vlan vlan-id1 [ to vlan-id2 ] 8021p 8021p-value1 [ to
8021p-value2 ]stack-vlan vlan-id3 [ remark-8021p 8021p-value3 ].
VLAN stacking based on the VLAN priority is supported only on the E-series and F-series
boards.
----End
5.6.3 (Optional) Configuring VLAN Priority Mapping on the
Outbound Interface
Procedure
Step 1 Run:
Quidway S7700 Smart Routing Switch
Configuration Guide - Ethernet 5 QinQ Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
199
