Huawei S1720 User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
134
Figure 9-15 Configure Guest VLAN for Interface
Step 3 Select interface number of Guest VLAN to be configured from Interface Name.
Step 4 Enter specified Guest VLAN ID number for interface in VLAN ID.
Step 5 Click Apply button to apply all the changes made. The successfully configured Guest VLAN
entry of interface will display in Guest VLAN list.
----End
9.4 Storm Suppression
9.4.1 Storm Control
Use Storm Control page to configure multicast, broadcast and unicast traffic control threshold.
Click Security> Strom Suppression > Storm Control, the configuration page is displayed as
follows.
Figure 9-16 Storm Control
Table 9-12 Parameters of Storm Control
Item
Description
Query Interval
The query interval sets the time that the unicast, multicast and
broadcast packet statistics transmitting from switch chip to storm
control. These packets statistics are the key factor to decide when the
inbound packet exceeds the threshold value. (Range: 1-300 seconds,
Default: 5 seconds).
Interface Name
Display the Interface Number.

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
