Huawei S1720 User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
10 Network
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
192
Step 4 Click Apply button to apply all the changes made.
----End
10.2.4 Event
Event group is used to define the index number and event process mode. The events that
defined by event group is used in configuration items of alarm group and extend configuration
items of alarm group. When the monitored object reachs alarm conditions, it will trigger the
event.
Click Network>RMON>Event, the configuration page is displayed as follows.
Figure 10-22 Event
Table 10-12 Parameters of Event
Item
Description
Entry
Number of event group entries.
Description
Description of event group.
Event Type
None: do not choose the event type.
Log: Records the event information (the time and the contents of
event, etc.) into the device event log table in RMON MIB in order to
be viewed by the management device through SNMP GET
operation.
Trap: Sends a Trap message to network management station to
inform the incident event.
Log and Trap: Records the log into the device, as well as to send
Trap messages to the network management station.
Last Time Send
The time that sends the event to the community at last
Owner
Create the user name of alarm group.
Create a RMON Event Group
Step 1 Click Network>RMON.
Step 2 Click Event in Tab, and click New to add an event, the configuration page is displayed as
follows.

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
