9.12 Interface Isolation
Isolation features of the interface are designed for security. Network administrators can add
certain interfaces (Common Interface and Trunk port) to isolation group. The isolation
interfaces within these groups cannot communicate directly, and other communications will
not be affected.
9.12.1 Two-way Isolation
The interfaces that enable Two-way Isolation cannot communicate directly; other
communications will not be affected.
Click Security > Interface Isolation > Two-way Isolation, the configuration page is displayed
as follows.
Figure 9-51 Two-way Isolation
Table 9-34 Parameters of Two-way Isolation
Item
Description
Query
Search the two-way Isolation settings of specified interface in
Interface Name.
Interface Name
Interface number
Status
Enable or disable the interface isolation on appropriate interfaces.
Set the parameters of Two-way Isolation for interface
Step 1 Click Security > Interface Isolation.
Step 2 Click Two-way Isolation in Tab.
Step 3 Click the check box of the two-way Isolation parameter on left side, and then click Configure
button to display the following page:

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
